Product description:
STRUCTURE
• NEW rebated or non-rebated door leaf manufactured with STILE frame technology
(except FRAGI 9 and 10)
• vertical and horizontal MDF slats with GREKO, PREMIUM, ST CP L or ST CPL veneer,
with AntiFinger coating
• vertical frame elements made of laminated wood, covered with HDF and MDF boards 3)
• in the case of a rebated window leaf, the glass does not adhere to the seal due to the recessed glass at the top
(a technological gap remains)
• optionally, door frame widening panels, as well as crown molding and
pilasters are available for an additional charge. p. 151-153.
HARDWARE
• three, 2-pin silver hinges in the rebated door leaf with horizontal adjustment
• three, silver-colored (optionally black at an additional cost) concealed hinges in the non-rebated door leaf; the hinges are delivered and priced with the door frame
• latch lock in the rebated door leaf, key lock, lock insert, keyless or bathroom lock mechanism locking magnetic lock
(optionally latch lock) in silver; optional black or gold
magnetic lock at an additional cost
GLAZING
• 8 mm tempered glass or tempered and glued VSG/ESG 441 frosted glass or black
safety glass, smooth on both sides (FRAGI 15 and FRAGI 16 models), in material
tinted smooth glass (FRAGI 17) NEW or decorative tempered glass 8 mm relief
(FRAGI 18) and point (FRAGI 19) NEW Relief and point glass smooth on one side.
• the glazing can be reversed to REWERS type (standard glazing: AWERS)
EXTRAS AT A CHARGE
factory drilling for door handles with (so-called split) leaf, when ordered in a set
lower ventilation opening
metal hinge cover in the rebated door leaf
(colour: brushed nickel, patina, polished chrome, polished brass, white and black)
replacement for black or gold magnetic lock for non-rebated door leaves
replacement of the lock for black lock for rebated door leaves 6).
replacement of the hinges for black hinges for rebated door leaves 6).
replacement for black or gold hinges and strike plate for non-rebated door leaves
magnetic limiter (stop)
(available in six colours p. 149)
vertical frame elements made of glued wood 3)
